Film Manufacturing

1. Rubber roller for film orientation

Name	Applications	Property	Type	Recommendable hardness (Type A)
Cast section Nip roller	Nipping cooled film after T-die extrusion	Anti-abrasion Surface property	Epitry Neobest Nonblow	50～70 50～70 50～70
		Heat resistance, Release property	SILBEST	50～70
Orientation section (Mechanical direction) Nip roller	Nip roller for orientation	Heat resistance, Release property, Anti-abrasion Less film edge marking	SILBEST Silqueen	60～80 60～80
		(Low temperature orientation property)	Chlowell Epitry	60～80 60～80
Guide section Guide roller Pinch roller	Guiding and infeeding film	Ozone-proof Anti-abrasion	Chlowell Epitry Neobest Neobest	50～80 50～80 50～80 50～80
	Anti-static	Less static generation Anti-static	Epitry Neobest COULOMB E,N	50～80 50～80 50～80
Rewind section Expander roller	Wrinkle elimination Film stability	Ozone-proof Anti-abrasion	Chlowell Epitry SILBEST	70 70 70
Touch roller	Film rewinding stability Wrinkle elimination	Ozone-proof, Surface property	Neobest	50～70
		Low μ	Nonblow	50～70
Slitting section Contact roller	Wrinkle elimination Film stability	Anti-abrasion Surface property	Epitry Neobest	60～70 60～70
	Film rewinding stability Wrinkle elimination	Surface property μ stability	Epitry Neobest	50～70 50～70
		Low μ	Nonblow SILBEST	40～70 40～70
Corona treater Corona treater roller	Corona treater roller	Heat-resistance, Ozone-proof Surface property Insulation breakdown voltage Electro conductivity	Silqueen SILBEST Chlowell Epitry	70 70 70 70

2. Rubber roller for gravure/flexographic printing

Name	Applications	Property	Type	Recommendable hardness (Type A)
Flexo printing Fountain roller	Inking roller	Ink resistance Aromatic hydrocarbon resistance Aliphatic hydrocarbon resistance	Nonwear Nonwear	60～70 60～70
		Polar solvent resistance	Nightly	60～70
Gravure printing Furnisher roller	Inking roller	Ink resistance Aromatic hydrocarbon resistance Aliphatic hydrocarbon resistance	Nonwear KINYO BROWN	30～40 30～40
		Polar solvent resistance	Nightly	30～40
Impression roller	Impression roller	Anti-abrasion Surface property Pressure resistance	Nonwear Nonwear Nonwear Nightly	60～80 60～80 80 60～80
		Less static generation Anti-static	Nonwear Nightly COULOMB E,N	60～80 60～80 60～80

3. Rubber roller for lamination

Name	Applications	Property	Type	Recommendable hardness (Type A)
Wet/dry lamination Solventless lamination	Coating roller	Aromatic hydrocarbon resistance Aliphatic hydrocarbon resistance	Nonblow/Nonblow AP1 Nonblow/Nonblow AP2 KINYO BROWN	30～50 50～80 30～80
		Polar solvent resistance	Epitry 62B	50～80 30～50
Lamination roller	Solventless adhesive Coating roller	Heat-resistance	Chlowell Epitry Fluoro elastomer resin tube	60～85 60～85
	Back-up roller	Surface property Anti-abrasion	Nonblow Epitry	50～80 50～80
	Lamination roller	Ozone-proof Surface property Release property	CHROMY Neobest SILBEST	60～80 60～80 60～80
		Less static generation Anti-static	Nonwear/Nonwear EC Neobest/Neobest EC Electro-conductive　 SILBEST COULOMB E,N	60～80 60～80 60～70 60～80
Extrusion lamination	Lamination nip roller	Ozone-proof Anti-abrasion Release property	Chlowell Silqueen SILBEST	60～80 50～80 50～80

4. Rubber roller for embossing

Name	Applications	Property	Type	Recommendable hardness (Type A)
Embossing Sand contained emboss roller	Film emboss Mat processing	Mat property Emboss property Heat- resistance Release property	SILBEST Sand contained Sand grit size 180 240 270 320 400 600 800	70,75 60,70,75 70,75 60,70,75 60,70,75 60,70,75 70
		Mat property Emboss property Anti-abrasion	68M 220 270 320 400 800	60,70,75 70,75 70,75 70,75 70
		Mat property Emboss property Anti-abrasion	18C 220 270 320 400 800	50,60,70,80 50,60,70,80 50,60,70,80 70,80 70
Emboss back roller	Back roller for metal roller embossing	Film property Release property Heat- resistance Anti-abrasion	SILBEST Silqueen Epitry	70～80 70～80 70～80
Extrusion embossing nip roller	Nip roller for embossing	Heat- resistance Release property	SILBEST	70～80
